The Laser Lightning Rod project

T. Produit, T. Produit, P. Walch, C. Herkommer, A. Mostajabi, M. Moret, U. Andral, A. Sunjerga, M. Azadifar, Y.-B. André, B. Mahieu, W. Haas, B. Esmiller, G. Fournier, P. Krötz, T. Metzger, K. Michel, A. Mysyrowicz, M. Rubinstein, F. Rachidi, J. Kasparian, J.-P. Wolf, A. Houard, “The Laser Lightning Rod project,” The European Physical Journal, Applied Physics 92, 30501 (2020) http://dx.doi.org/10.1051/epjap/2020200243

Lightning is highly destructive due to its high power density and unpredictable character. Directing lightning away would allow to protect sensitive sites from its direct and indirect impacts (electromagnetic perturbations). Up to now, lasers have been unable to guide lightning efficiently since they were not offering simultaneously terawatt peak powers and kHz repetition rates. In the framework of the Laser Lightning Rod project, we develop a laser system for lightning control, with J-range pulses of 1 ps duration at 1 kHz. The project aims at investigating its propagation in the multiple filamentation regime and its ability to control high-voltage discharges. In particular, a field campaign at the Säntis mountain will assess the laser ability to trigger upward lightning.

(a) Principle of the general layout of the laser experiment implementation at Säntis (not to scale). (b) Schematic drawing of the sending telescope.

Machine Learning-Based Lightning Localization Algorithm Using Lightning-Induced Voltages on Transmission Lines

H. Karami; A. Mostajabi; M. Azadifar; M. Rubinstein; C. Zhuang et al. “Machine Learning-Based Lightning Localization Algorithm Using Lightning-Induced Voltages on Transmission Lines,” IEEE Transactions on Electromagnetic Compatibility. 2020. Vol. 62, num. 6, p. 2512-2519. https://doi.org/10.1109/TEMC.2020.2978429

In this article, we present a machine learning-based method to locate lightning flashes using calculations of lightning-induced voltages on a transmission line. The proposed approach takes advantage of the preinstalled voltage measurement systems on power transmission lines to get the data. Hence, it does not require the installation of additional sensors such as extremely low frequency, very low frequency, or very high frequency. The proposed model is shown to yield reasonable accuracy in estimating two-dimensional geolocations for lightning strike points for different grid sizes up to 100 × 100 km 2 . The algorithm is shown to be robust against the distance between the voltage sensors, lightning peak current, lightning current rise time, and signal to noise ratio of the input signals.

Ultrafast thin-disk multipass amplifier with 720 mJ operating at kilohertz repetition rate for applications in atmospheric research

C. Herkommer, P. Krötz, R. Jung, S. Klingebiel, C. Wandt, R. Bessing, P. Walch, T. Produit, K. Michel, D. Bauer, R. Kienberger, and T. Metzger, “Ultrafast thin-disk multipass amplifier with 720 mJ operating at kilohertz repetition rate for applications in atmospheric research,” Optics Express 28, 30164 (2020) https://doi.org/10.1364/OE.404185

We present an ultrafast thin-disk based multipass amplifier operating at a wavelength of 1030 nm, designed for atmospheric research in the framework of the Laser Lightning Rod project. The CPA system delivers a pulse energy of 720 mJ and a pulse duration of 920 fs at a repetition rate of 1 kHz. The 240 mJ seed pulses generated by a regenerative amplifier are amplified to the final energy in a multipass amplifier via four industrial thin-disk laser heads. The beam quality factor remains ∼ 2.1 at the output. First results on horizontal long-range filament generation are presented.

Measurement and Modeling of Both Distant and Close Electric Fields of an M-Component in Rocket-Triggered Lightning

Q. Li; F. Rachidi; M. Rubinstein; J. Wang; L. Cai et al. “Measurement and Modeling of Both Distant and Close Electric Fields of an M-Component in Rocket-Triggered Lightning,” Journal of Geophysical Research: Atmospheres. 2020. Vol. 125, num. 21. https://doi.org/10.1029/2019JD032300

Simultaneous measurements of current and multiple-station electric fields associated with a 5.4-kA-peak M-component in rocket-triggered lightning are presented in this study. A close-range electric field measurement site was located northeast of the triggering site, 195° clockwise from South, at a distance of 78 m, while the distant multiple stations in this study were located southwest of the lightning triggering site (25–48°, clockwise from South) at a distance ranging from 69 to 126 km. Both the fast microsecond-scale and slow millisecond-scale pulses were observed at six distant stations. At the close station, the fast pulse was not noticeable. The magnitude and half-peak width of the fast pulse were in the range of 0.91–1.93 V/m and 2.0–3.0 μs, respectively. The corresponding parameters for the slow pulse were, respectively, in the range of 0.59–1.29 V/m and 20.0–25.1 μs. The time lag between the onset of the channel-base current and the far electric field of the M-component was 18 μs. This time lag was used to deduce the ratio of the M-component channel length and the wave speed. The classical guided wave M-component model proposed by Rakov et al. (1995, https://doi.org/10.1029/95JD01924) to simulate the slow, millisecond-scale field pulse assumes that neither the incident nor the reflected current wave undergoes attenuation even though the wave propagation occurs along a lossy channel. A modified guided wave M-component model is proposed in this study in which the M-component current wave attenuates with an exponential decay. Based on the best agreement achieved between the simulated fields using the modified two-wave M-component model and the observed near and far electric fields, the channel length, the M-component wave speed, and the current attenuation constant were inferred, respectively, as 1.8 km, 1 × 108 m/s, and 3 km. It is shown that the modified guided wave M-component model is able to reproduce reasonably well the electric fields both at close and far distance ranges.

Dynamics of the femtosecond laser-triggered spark gap

E. W Rosenthal, I. Larkin, A. Goffin, T. Produit, M. C. Schoeder, J.-P. Wolf and H. M. Milchberg, “Dynamics of the femtosecond laser-triggered spark gap,” Optics Express 28, 24599 (2020) https://doi.org/10.1364/OE.398836

We present space and time resolved measurements of the air hydrodynamics induced by femtosecond laser pulse excitation of the air gap between two electrodes at high potential difference. We explore both plasma-based and plasma-free gap excitation. The former uses the plasma left in the wake of femtosecond filamentation, while the latter exploits air heating by multiple-pulse resonant excitation of quantum molecular wavepackets. We find that the cumulative electrode-driven air density depression channel plays the dominant role in the gap evolution leading to breakdown. Femtosecond laser heating serves mainly to initiate the depression channel; the presence of filament plasma only augments the early heating.

The Polarity Reversal of Lightning- Generated Sky Wave

W. Hou; M. Azadifar; M. Rubinstein; F. Rachidi; Q. Zhang, “The Polarity Reversal of Lightning- Generated Sky Wave,” Journal of Geophysical Research: Atmospheres. 2020. Vol. 125, num. 17, p. 1-17, e2020JD032448. https://doi.org/10.1029/2020JD032448

The polarity reversal of the lightning-generated first sky wave as a function of the observation distance is studied using a novel approach combining the finite-difference time domain (FDTD) method and the superposition principle of electromagnetic waves. In this method, the sky wave is generated by radiation from the induced current produced by the motion of charged particles driven by the lightning-radiated electromagnetic waves in the ionosphere. The horizontal and vertical components of the induced current density under the daytime and nighttime ionospheric conditions are evaluated. Their different contributions to the sky wave at different observation distances are analyzed in detail. Furthermore, a physical explanation for the polarity reversal in the time domain is proposed. It is found that, for relatively short observation distances (within ~200 km), the first sky wave is dominated by the component generated by the horizontal equivalent current in the Fresnel zone, while for longer observation distances (larger than ~300 km), the first sky wave is dominated by the component generated by the vertical equivalent current in the Fresnel zone. Since the polarities of the sky wave components generated by the vertical current source and horizontal current source are opposite, the polarity of the sky wave will reverse when increasing the observation distance.

Nowcasting lightning occurrence from commonly available meteorological parameters using machine learning techniques

A. Mostajabi, D. L. Finney, M. Rubinstein, F. Rachidi, npj Climate and Atmospheric Science 2, 41 (2019)
Link

Abstract: Lightning discharges in the atmosphere owe their existence to the combination of complex dynamic and microphysical processes. Knowledge discovery and data mining methods can be used for seeking characteristics of data and their teleconnections in complex data clusters. We have used machine learning techniques to successfully hindcast nearby and distant lightning hazards by looking at single-site observations of meteorological parameters. We developed a four-parameter model based on four commonly available surface weather variables (air pressure at station level (QFE), air temperature, relative humidity, and wind speed). The produced warnings are validated using the data from lightning location systems. Evaluation results show that the model has statistically considerable predictive skill for lead times up to 30 min. Furthermore, the importance of the input parameters fits with the broad physical understanding of surface processes driving thunderstorms (e.g., the surface temperature and the relative humidity will be important factors for the instability and moisture availability of the thunderstorm environment). The model also improves upon three competitive baselines for generating lightning warnings: (i) a simple but objective baseline forecast, based on the persistence method, (ii) the widely-used method based on a threshold of the vertical electrostatic field magnitude at ground level, and, finally (iii) a scheme based on CAPE threshold. Apart from discussing the prediction skill of the model, data mining techniques are also used to compare the patterns of data distribution, both spatially and temporally among the stations. The results encourage further analysis on how mining techniques could contribute to further our understanding of lightning dependencies on atmospheric parameters.
